I recently came across a need to review the Storage Policies in use within a vCenter environment and how many objects or virtual machines where using each policy.
I saw this as an excuse to refresh my PowerShell skills and wrote a quick function.
Source code can be found on my GitHub, here. Check there for any updates but below is the code at the time of writing.
1function Get-vSANSPSummary {
2 <#
3 .SYNOPSIS
4 Export vSAN Storage Policy Information.
5 .DESCRIPTION
6 Export vSAN Storage Policies from vCenter showing FTT & Stripe information and amount of amount of VM's using each.
7 .PARAMETER ExportPath
8 Path the export the output HTML file.
9 .NOTES
10 Tags: VMware, vCenter, SPBM, PowerCLI, API
11 Author: Stephan McTighe
12 Website: stephanmctighe.com
13 .EXAMPLE
14 PS C:\> Get-vSANSPSummary -ExportPath "C:\report\vSAN-Storage-Policy-Summary.html"
15 Outputs a HTML file containing the Storage Policy Information for vSAN Storage Policies to a specified location.
16
17#>
18#Requires -Modules VMware.VimAutomation.Storage
19 [CmdletBinding()]
20 param (
21 [Parameter(Mandatory)]
22 [string] $ExportFilePath)
23
24 Begin {}
25
26 Process {
27 try {
28 $Output = @()
29 $vSANstoragepolicies = Get-SpbmStoragePolicy -Namespace "VSAN"
30 $SPBM = $vSANstoragepolicies | Select-Object Name, AnyOfRuleSets
31 ForEach ($SP in $SPBM) {
32 $Attributes = @( $SP | ForEach-Object { $_.AnyOfRuleSets } | Select-Object -ExpandProperty AllofRules)
33 $object = [PSCustomObject]@{
34 SPName = $SP.Name
35 ObjectCount = $ObjectCount = (Get-SpbmEntityConfiguration -StoragePolicy "$($SP.name)").count
36 VMCount = $VMCount = (Get-SpbmEntityConfiguration -StoragePolicy "$($SP.Name)" | Where-Object {$_.Entity -notlike "hard*"}).count
37 RAID = $attributes | Where-Object { $_.Capability -like "*VSAN.replicaPreference*" } | Select-Object -ExpandProperty Value
38 FTT = $attributes | Where-Object { $_.Capability -like "*VSAN.hostFailuresToTolerate*" } | Select-Object -ExpandProperty Value
39 SubFTT = $attributes | Where-Object { $_.Capability -like "*VSAN.subFailuresToTolerate*" } | Select-Object -ExpandProperty Value
40 Stripes = $attributes | Where-Object { $_.Capability -like "*VSAN.stripeWidth*" } | Select-Object -ExpandProperty Value
41 ForceProvision = $attributes | Where-Object { $_.Capability -like "*VSAN.forceProvisioning*" } | Select-Object -ExpandProperty Value
42 StorageType = $attributes | Where-Object { $_.Capability -like "*VSAN.storageType*" } | Select-Object -ExpandProperty Value
43 IOPSLimit = $attributes | Where-Object { $_.Capability -like "*VSAN.iopsLimit*" } | Select-Object -ExpandProperty Value
44
45 }
46 $Output += $object
47
48 }
49 $Output | ConvertTo-Html -Property SPName, VMCount, ObjectCount, RAID, FTT, SubFTT, Stripes, ForceProvision, StorageType, IOPSLimit | Out-File $ExportFilePath
50 }
51 catch {
52 Write-Host "An error occurred!" -ForegroundColor Red
53 Write-Host $_ -ForegroundColor Red
54 }
55
56 }
57}Output currently as a basic HTML table but you could change this to add some ‘HTMLness’ or output to CSV.
C:\Users\Peppa\OneDrive - stephanmctighe.com\Documents\GitHub_Repos\stephanmctighe.com\content\posts\vSAN Storage Policy Summary using PowerCLI\images\image1.jpg
As always, thanks for reading and I hope this has been useful to someone.
